- Waga
- 0.32 kg
- Informacje dodatkowe
- Gigabit LAN Port
- Data IN / PoE: RJ45 Shielded Socket
- Rated Voltage: 100-240VAC @ 50/60Hz
- Output Voltage: 24VDC @ 1.0A
- Input Current: 0.6A @ 120VAC, 0.4A @ 240VAC
- Inrush Current: <60A Peak @ 120VAC, <120A Peak @ 230VAC
- Efficiency: 80+%
- Output Ripple: 1% Max.
- Switching Frequency: 65 kHz
- Line Regulation: <=3%
- Load Regulation: <=5%
- 2-Pair Powering: Pins 4, 5 (+) and Pins 7, 8 (-)
- Operating Temperature : 0-40° C (32-104° F)
- Storage Temperature: -30-70°C (-22-158° F)
- Operating Humidity: 35-95% Noncondensing
- AC Connector: IEC-320 C6
- Surge Protection: Difference and Common Mode
- Clamping Protection: 11V Data, 60V Power
- Max. Surge Discharge: 1500A (8/20 µs) Power
- Peak Pulse Current: 36A (10/1000 µs) Data
- Shunt Capacitance: <5 pF data
- Response Time: <1 ns
- Remote Reset Capability, Reset Button
- Dimensions: 88 x 57 x 33 mm
- Weight: 158.5 g
- Certifications: CE, FCC, IC, UL
