- Waga
- 0.3 kg
- Informacje dodatkowe
- Dimensions: 88 x 57 x 33 mm
- Weight: 135,5 g
- Output Voltage: 48VDC @ 0,5A
- Rated Voltage: 100-240VAC @ 50/60Hz
- Input Current: 0,6A @ 120VAC, 0,4A @ 240VAC
- Inrush Current: <60A Peak @ 120VAC, <120A Peak @ 230VAC
- Efficiency: 80+%
- 2-Pair Powering: Pins 4, 5 (+) and Pins 7, 8 (-)
- Operating Temperature: 0 to 40° C
- Storage Temperature: -30 to 70°C
- Clamping Protection: 11V Data, 60V Power
- Max. Surge Discharge: 1500A (8/20 µs) Power
- Peak Pulse Current: 36A (10/1000 µs) Data
- Shunt Capacitance: <5 pF data
- Response Time: <1 ns
- Certifications: CE, FCC, IC, UL
