- Waga
- 5.03 kg
- Rodzaj urządzenia przewodowego
- Switch zarządzalny
- Ilość portów
- 28
- Ilość portów RJ-45 1GbE
- 24 szt.
- Ilość portów SFP 1GbE
- 4 szt.
- Port PoE
- Tak
- Ilość portów PoE
- 24
- Obsługiwane protokoły / Zgodność z normami
- IEEE 802.3 10 Base-T (RJ45)
- IEEE 802.3u 100 Base-T (RJ45)
- IEEE 802.3ab 1000 Base-T (RJ45)
- IEEE 802.3x Flow control
- IEEE 802.3ad Link Aggregation Control Protocol (LACP)
- IEEE 802.3z Gigabit Ethernet
- IEEE 802.1p Priorytetyzacja ruchu
- IEEE 802.1Q VLAN (Virtual Local Area Network - Dot1q)
- IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
- IEEE 802.1D STP (Spanning Tree Protocol)
- IEEE 802.1S Multiple Spanning Tree Protocol (MSTP)
- IEEE 802.3af/at Power-over-Ethernet (PoE)
- Dodatkowe funkcje urządzenia
- DHCP
- QoS (Quality of Service)
- Zarządzanie zdalne
- Ochrona przed atakami DoS
- Rozmiar tablicy MAC
- 16 K
- Przepustowość (Gb/s)
- 56.0
- Szybkość przekierowań pakietów (Mpps)
- 41.70
- Wymiary [G x S x W] (mm)
- 178,8 x 440 x 44
- Informacje dodatkowe
- Switching buffer: 12Mbit
- Store and forward, static/dynamic port aggregation supported
- Lightning protection: 6 kV (port, power)
- Management and maintenance:
- - Supports Telnet configuration, Console port configuration
- - Supports SNMP V1/V2/V3
- - Supports WEB management and maintenance
- - Supports Ping/Tracert Detection
- Supports: ARP receiving limit, unknown MAC address discard
- Cloud management:
- - Supports configuration delivery from IMS cloud platform
- - Supports log reporting and fault detection
- - Supports remote maintenance: reboot, backup, upgrade
- Three port modes: Access, Trunk and Hybrid
- Whole switch consumption:
- - Whole switch consumption: < 410 W
- - Maximum PoE output power: 370 W
- PoE power supply management:
- - Supports port PoE configuration and power supply with priorit
- - Supports PoE over-temperature protection
- - Supports PoE scheduled management
- - Supports intelligent and graphical management and PoE-powered device
- detection (port status, power assignment and PoE-powered device status)
- Certificates: CCC / FCC / CE / RoHS
- Gwarancja producenta [mies.]
- 36
