- Waga
- 1 kg
- Rodzaj urządzenia bezprzewodowego
- Przekaźnik
- Obsługiwane protokoły / Zgodność z normami
- IEEE 802.11ac Połączenie bezprzewodowe (Wi-Fi 5)
- Częstotliwość pracy
- 2,4 GHz i 5 GHz
- Bezpieczeństwo
- WPA2
- Tryb pracy
- Access Point / Punkt dostępowy
- Station (Client)
- Port PoE
- Tak
- Wymiary [G x S x W] (mm)
- 88 x 40 x 230
- Waga netto (kg)
- 0.400
- Zawiera baterię / akumulator
- Nie
- Informacje dodatkowe
- Networking Interface: (1) 10/100/1000 Ethernet Port
- RF Connectors: (2) RP-SMA (Waterproof ), (1) GPS* (Waterproof )
- * Reserved for future use
- LEDs: (4) Signal Strength, GPS*, Power, LAN
- Enclosure: Die-Cast Aluminum with White Powder Coating
- Max. Power Consumption: 9.5W
- Power Supply: 24V, 1A Gigabit PoE Adapter (Included)
- Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
- Processor Specs: Atheros MIPS 74Kc
- Memory: 128 MB DDR2 SDRAM
- Supported Voltage Range: 18-26VDC
- Signal Strength LEDs: Software-Adjustable to Correspond to Custom RSSI Leve
- Channel Sizes - PtP Mode: 10/20/30/40/50/60/80 MHz
- Channel Sizes - PtMP Mode: 10/20/30/40 MHz
- ESD/EMP Protection: ± 24 kV Contact / Air for Ethernet
- Operating Temperature: -40 to 80° C (-40 to 176° F)
- Operating Humidity: 5 to 95% Noncondensing
- RoHS Compliance: Yes
- Shock and Vibration: ETSI300-019-1.4
- Services: Web Server, SNMP, SSH Server, Telnet , Ping Watchdog, DHCP, NAT
- Services: Bridging, Routing
- Utilities: Antenna Alignment Tool, Discovery Utility, Site Survey, Ping
- Utilities: Traceroute, Speed Test
- Distance Adjustment: Dynamic Ack and Ackless Mode
- Power Adjustment: Software Adjustable UI or CLI
- QoS: Supports Packet Level Classification WMM and User Customer Level: High
- /Medium/Low
- Statistical Reporting: Up Time, Packet Errors, Data Rates,Wireless Distance
- Statistical Reporting: Ethernet Link Rate
- Remote Reset Support, Software Enabled/Disabled
- VLAN Support, 256QAM, GPS*, TX Filter
- 30/50/60 MHz Channels, airMAX ac Mode, Traffic Shaping with Burst Support
- Discovery Protocol, Frequency Band Offset, Ackless Mode
- Certifications: CE, FCC, IC
