- Waga
- 2.1 kg
- Gniazdo procesora
- Socket 1851
- Obsługiwane typy procesorów
- Intel Core Ultra Processors (series 2)
- Format płyty
- ATX
- Chipset płyty głównej
- Intel® Z890
- Ilość złącz pamięci DDR5
- 4
- Maksymalna wielkość pamięci
- 256 GB
- Tryb pracy pamięci RAM
- Dual Channel
- Uwagi do pamięci RAM
- Max. overclocking frequency:
- - 1DPC 1R Max speed up to 9200+ MT/s
- - 1DPC 2R Max speed up to 7200+ MT/s
- - 2DPC 1R Max speed up to 4800+ MT/s
- - 2DPC 2R Max speed up to 4800+ MT/s
- Supports Intel POR Speed and JEDEC Speed
- Supports Memory Overclocking and Intel XMP 3.0
- Supports Dual-Controller Dual-Channel mode
- Supports Non-ECC, Un-buffered memory
- Supports CUDIMM
- Memory Support 9200 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s
- Zintegrowany kontroler SATA
- Chipset+CPU: 4x SATA III 6Gb/s + 5x M.2
- Uwagi do kontrolera SATA
- - M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 ,
- supports 2280/2260 devices
- - M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 ,
- supports 2280/2260 devices
- - M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 ,
- supports 2280/2260 devices
- - M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 ,
- supports 22110/2280 devices
- - M.2_5 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode,
- supports 2280/2260 devices
- M2_4 default from chipset, can support PCIe 5.0 x4 (From CPU) by manual
- BIOS adjustment
- Gniazda karty graficznej
- HDMI
- 2x Thunderbolt™ 4 (USB Type-C®)
- Uwagi do karty graficznej
- Support HDMITM 2.1 with FRL port, maximum resolution of 8K 60Hz
- Thundebolt 4 ports supporting DisplayPort 1.4 with HBR3 over USB Type-C,
- with a maximum resolution of 8K@60Hz
- Graphics specifications may vary depending on the CPU installed
- Zintegrowana karta dźwiękowa
- Realtek® ALC4082 Codec + ESS9219Q Combo DAC/HPA
- Gniazda karty dźwiękowej
- Wewnętrzne gniazdo audio przedniego panelu
- 2x Audio Jack
- Wyjście optyczne S/PDIF
- Uwagi do karty dźwiękowej
- Supports up to 32-Bit/384 kHz playback on front panel
- Złącza PCI Express x16
- 3
- Uwagi do złącz PCI
- - PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
- - PCI_E2 Gen PCIe 5.0 supports up to x8 (From CPU)
- - PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
- - PCI_E1 support manual BIOS adjustment to X8+X8/X8+X4+X4
- - PCI_E2 support manual BIOS adjustment to X4+X4
- - PCI_E1 slot will run at x8 speed when PCI_E2 slot installing device
- - PCI_E1 slot will run at x8 speed and PCI_E2 slot will run at x4 speed
- when installing PCIe Gen 5 M.2 device in the M2_4 slot
- Port LAN
- 1x 10 Gigabit LAN Marvell® AQC113CS
- Maksymalna ilość portów USB 2.0
- 4
- Maksymalna ilość portów USB 3.x
- 18
- Porty USB na panelu tylnym
- 11x USB 3.1 + 2x USB 3.1 Type-C
- Gniazda USB na płycie głównej
- 2x USB 2.0 (2 porty) + 2x USB 3.0 (4 porty) + 1x USB 3.2 Type-C (1 port)
- Port Wi-Fi
- IEEE 802.11a/b/g/n/ac/ax/be
- Port Bluetooth
- Bluetooth V5.4
- Uwagi do WiFi / BT
- Intel® Killer™ BE1750x Wi-Fi 7
- The Wireless module is pre-installed in the M.2 (Key-E) slot
- Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps
- Supports 802.11 a/ b/ g/ n/ ac/ ax/ be
- Supports Bluetooth® 5.4**, MLO, 4KQAM
- 6GHz band support may depend on every country’s regulations and Wi-Fi 7
- will be ready in Windows 11 version 24H2
- The Bluetooth version may be updated, please refer to the Wi-Fi chipset
- vendor's website for details. Bluetooth 5.4 will be ready in Windows 11
- version 24H2
- Port PS/2
- Brak
- Port szeregowy (COM)
- Brak
- Port równoległy (LPT)
- Brak
- Inne porty i gniazda
- Thunderbolt 5 card connector(JTBT5, support RTD3)
- Front Type-C Quick Charge Connector(PD_PWR1)
- 2x Combo Fan (Pump_Sys Fan)
- 5x System Fan
- EZ Conn-header (JAF_2)
- 2x Front Panel
- Chassis Intrusion (JCI)
- Water Flow connector
- Slow mode booting jumper
- 2x Thermal Sensor connectors
- Tuning Controller Connector
- 3x Addressable V2 RGB LED connector
- RGB LED connector
- Gniazdo modułu TPM
- V-check point
- Clear CMOS button(s)
- Wymiary [S x W] (mm)
- 243,84 x 304,8
- Opakowanie
- BOX
- Zawiera baterię / akumulator
- Tak
- Informacje dodatkowe
- Support for Windows 11 64-bit
