- Waga
- 2.19 kg
- Gniazdo procesora
- Socket 1851
- Obsługiwane typy procesorów
- Intel Core Ultra Processors (series 2)
- Uwagi do procesora
- Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max 3.0
- Refer to https://www.asus.com/support/download-center/ for CPU support list
- Intel Turbo Boost Max Technology 3.0 support depends on the CPU types
- Format płyty
- ATX
- BIOS
- 256 Mb Flash ROM, UEFI AMI BIOS; WOL by PME, PXE
- Chipset płyty głównej
- Intel® B860
- Ilość złącz pamięci DDR5
- 4
- Maksymalna wielkość pamięci
- 256 GB
- Tryb pracy pamięci RAM
- Dual Channel
- Standard pamięci
- DDR5-8600 (OC)
- Uwagi do pamięci RAM
- Supports up to 8600+MT/s (OC), Non-ECC Un-buffered ,Clocked Unbuffered DIMM
- Supports Intel® Extreme Memory Profile (XMP) memory module
- ASUS Enhanced Memory Profile III (AEMP III)
- DIMM Fit
- Zintegrowany kontroler SATA
- Chipset+CPU: 4x SATA III 6Gb/s + 4x M.2
- Uwagi do kontrolera SATA
- Intel® Core™ Ultra Processors(series 2):
- - M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
- Intel® B860 Chipset:
- - M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
- - M.2_3 slot (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode)
- - M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
- - 4 x SATA 6Gb/s ports
- Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10.
- M.2_4 slot shares bandwidth with PCIEX16(G4). When PCIEX16(G4) slot is
- operating, M.2_4 will be disabled
- Gniazda karty graficznej
- HDMI
- DisplayPort
- USB4 Type-C
- Uwagi do karty graficznej
- Graphics specifications may vary between CPU types. Please refer to
- www.intel.com for any updates.
- Supports max. 4K@60Hz as specified in DisplayPort 1.4
- Supports 4K@60Hz as specified in HDMI
- Supports max. 4K@60Hz as specified in DisplayPort 1.4a
- 4K@60Hz x 2, maximum total bandwidth up to 23.8Gbps or 16Gbps/16Gbps,
- In USB4® mode, supports up to 4K@60Hz, maximum total bandwidth up to
- 23.8Gbps, for resolution support please check DisplayPort 1.4 specs
- In DP alt mode, supports up to UHBR10
- VGA resolution support depends on processors' or graphic cards' resolution
- Zintegrowana karta dźwiękowa
- Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC
- Gniazda karty dźwiękowej
- Wewnętrzne gniazdo audio przedniego panelu
- 2x Audio Jack
- Wyjście optyczne S/PDIF
- Uwagi do karty dźwiękowej
- Impedance sense for front and rear headphone outputs
- Internal audio Amplifier to enhance the highest quality sound for
- headphone and speakers
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording
- input (Line-in)
- Supports up to 32-Bit/192 kHz
- SupremeFX Shielding Technology
- Savitech SV3H712 AMP
- Premium audio capacitors
- Dedicated audio PCB layers
- Audio cover
- Złącza PCI Express x16
- 2
- Uwagi do złącz PCI
- Intel Core Ultra Processors (series 2)
- - Intel® Core™ Ultra Processors (Series 2)
- Intel® B860 Chipset:
- - Intel® B860 Chipset
- M.2_4 slot shares bandwidth with PCIEX16(G4). When PCIEX16(G4) slot is
- operating, M.2_4 will be disabled
- Port LAN
- 1x 2,5 Gigabit LAN Intel®
- Uwagi do karty sieciowej
- ASUS LANGuard
- Maksymalna ilość portów USB 2.0
- 6
- Maksymalna ilość portów USB 3.x
- 8
- Maksymalna ilość portów USB 4.0
- 1
- Porty USB na panelu tylnym
- 4x USB 2.0 + 2x USB 3.0 + 2x USB 3.1 + 1x USB 3.1 Type-C +1x Thunderbolt 4
- Gniazda USB na płycie głównej
- 1x USB 2.0 (2 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.1 Type-C (1 port)
- Port Wi-Fi
- IEEE 802.11a/b/g/n/ac/ax/be
- Port Bluetooth
- Bluetooth V5.4
- Uwagi do WiFi / BT
- 2x2 Wi-Fi 7 (802.11be)
- Supports 2.4/5/6GHz frequency band
- Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate
- Wi-Fi features may vary depending on the operating system
- For Windows 11, Wi-Fi 7 will require 24H2 or later version for full
- functions, Windows 11 21H2/22H2/23H2 only supports Wi-Fi 6E
- For Windows 10, please note that no driver is available ,
- please refer to the Wi-Fi chipset vendor's website for details
- The Bluetooth version may vary
- Port PS/2
- Brak
- Port szeregowy (COM)
- Brak
- Port równoległy (LPT)
- Brak
- Inne porty i gniazda
- 4-pin CPU Fan header
- 4-pin CPU OPT Fan header
- 4-pin AIO Pump header
- 4x 4-pin Chassis Fan headers
- 3x Addressable Gen 2 header
- 10-1 pin System Panel header
- Thermal Sensor header
- Wi-Fi module with an antenna connector
- BIOS FlashBack button
- Clear CMOS button(s)
- Gniazdo zasilania
- ATX (24-pin) + 2x ATX12V (8-pin)
- Wymiary [S x W] (mm)
- 305 x 244
- Wyposażenie dodatkowe
- 2 x SATA 6Gb/s cables
- 1 x ASUS WiFi Q-Antenna
- 1 x Cable ties package
- 1 x M.2 Q-Latch
- 1 x M.2 Q-Slide
- 1 x ROG key chain
- 1 x ROG Strix stickers
- 4 x M.2 rubbers
- 1 x Quick start guide
- Zawiera baterię / akumulator
- Tak
- Informacje dodatkowe
- Operating System: Windows 11 (22H2 & later)
