- Waga
- 5.44 kg
- Gniazdo procesora
- Socket 1851
- Obsługiwane typy procesorów
- Intel Core Ultra Processors (series 2)
- Uwagi do procesora
- Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max 3.0
- Refer to https://www.asus.com/support/download-center/ for CPU support list
- Intel Turbo Boost Max Technology 3.0 support depends on the CPU types
- Format płyty
- Extended-ATX
- BIOS
- 2x 256 Mb Flash ROM, UEFI AMI BIOS; WOL by PME
- Chipset płyty głównej
- Intel® Z890
- Ilość złącz pamięci DDR5
- 4
- Maksymalna wielkość pamięci
- 192 GB
- Tryb pracy pamięci RAM
- Dual Channel
- Standard pamięci
- DDR5-8400+ (OC)
- Uwagi do pamięci RAM
- Support up to 8400+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM
- Supports Intel® Extreme Memory Profile (XMP) memory module
- ASUS Enhanced Memory Profile III (AEMP III)
- Supports DIMM Flex, Supports DIMM Fit, NitroPath DRAM Technology
- Zintegrowany kontroler SATA
- Chipset+CPU: 4x SATA III 6Gb/s + 6x M.2
- Uwagi do kontrolera SATA
- Intel® Core™ Ultra Processors(series 2):
- - M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)
- - M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
- - M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 modes
- - M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 modes)**
- Intel® Z890 Chipset:
- - DIMM.2_1 slot (Key M) via ROG Q-DIMM.2, type 2230/2242/2260/2280/22110
- (supports PCIe 4.0 x4 mode)
- - DIMM.2_2 slot (Key M) via ROG Q-DIMM.2, type 2230/2242/2260/2280/22110
- (supports PCIe 4.0 x4 mode)
- Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10,
- SATA RAID 0/1/5/10, M.2 slot from CPU only supports RAID 0/1/5
- M.2_3 & M.2_4 share bandwidth with PCIEX16(G5)_2
- When M.2_3 is enabled, PCIEX16(G5)_1 will run x8 & PCIEX16(G5)_2
- will run x4. When M.2_3 & M.2_4 are enabled, PCIEX16(G5)_1 will run x8 &
- PCIEX16(G5)_2 will disabled
- Gniazda karty graficznej
- HDMI
- 2x Thunderbolt™ 5 (USB Type-C®)
- Uwagi do karty graficznej
- Graphics specifications may vary between CPU types. Please refer to
- www.intel.com for any updates.
- Supports max. 8K@60Hz with DSC as specified in HDMI 2.1.
- Supports up to 1 x 8K@60HZ(DSC mode)+2 x 4K@60HZ monitors, It is recommend
- to chain-connect the monitors using a verified Thunderbolt™ cable
- For resolution support please check DisplayPort 2.1 specs.bandwidth limited
- by DisplayPort™ 2.1 with up to 77.4 Gbit/s
- VGA resolution support depends on processors' or graphic cards' resolution
- Zintegrowana karta dźwiękowa
- ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082
- Gniazda karty dźwiękowej
- Wewnętrzne gniazdo audio przedniego panelu
- 2x Audio Jack
- Wyjście optyczne S/PDIF
- Uwagi do karty dźwiękowej
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 120 dB SNR stereo playback output and 110 dB SNR recording in
- Supports up to 32-Bit/384 kHz playback on front panel
- Dedicated audio PCB layers
- SupremeFX Shielding Technology
- ESS ES9219 QUAD DAC
- LED-illuminated audio jacks
- Premium audio capacitors
- Złącza PCI Express x16
- 2
- Złącza PCI Express x4
- 1
- Uwagi do złącz PCI
- Intel Core Ultra Processors (series 2):
- - 2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 or x8/x4/x4 modes)**
- Intel® Z890 Chipset:
- - 1 x PCIe 4.0x4 slot
- Please check the PCIe bifurcation table on the support site
- (https://www.asus.com/support/FAQ/1037507/)
- M.2_3 & M.2_4 share bandwidth with PCIEX16(G5)_2. When M.2_3 is enabled,
- PCIEX16(G5)_1 will run x8 & PCIEX16(G5)_2 will run x4. When M.2_3 & M.2_4
- are enabled, PCIEX16(G5)_1 will run x8 & PCIEX16(G5)_2 will disabled
- Port LAN
- 1x 2,5 Gigabit LAN Realtek®
- 1x 10 Gigabit LAN Marvell® AQtion
- Uwagi do karty sieciowej
- ASUS LANGuard
- Maksymalna ilość portów USB 2.0
- 4
- Maksymalna ilość portów USB 3.x
- 14
- Maksymalna ilość portów USB 4.0
- 2
- Porty USB na panelu tylnym
- 5x USB 3.1 + 2x USB 3.1 Type-C + 1x USB 3.2 Type-C + 2x Thunderbolt 5 Type-C
- Gniazda USB na płycie głównej
- 2x USB 2.0 (4 porty) + 2x USB 3.0 (4 porty) + 1x USB 3.1 Type-C (1 port)+ 1x USB 3.2 Type-C (1 port)
- Port Wi-Fi
- IEEE 802.11a/b/g/n/ac/ax/be
- Port Bluetooth
- Bluetooth V5.4
- Uwagi do WiFi / BT
- 2x2 Wi-Fi 7 (802.11be)
- Supports 2.4/5/6GHz frequency band
- Support Wi-Fi 7 320MHz bandwidth, up to 5.8Gbps transfer rate.
- Wi-Fi features may vary depending on the operating system
- For Windows 11, Wi-Fi 7 will require 24H2 or later version for full
- functions, Windows 11 21H2/22H2/23H2 only supports Wi-Fi 6E
- For Windows 10, only Wi-Fi 6 is supported
- Port PS/2
- Brak
- Port szeregowy (COM)
- Brak
- Port równoległy (LPT)
- Brak
- Inne porty i gniazda
- 4-pin CPU Fan header
- 4-pin CPU OPT Fan header
- 2x 4-pin Chassis Fan headers
- 2x 4-pin Radiator Fan headers
- 2x W_PUMP+ headers
- WB_SENSOR header
- 6-pin ARGB Gen 2 header to support 2x ARGB Gen 2 headers
- 2x Addressable Gen 2 header
- Alteration PCIe mode switch
- 10-1 pin System Panel header
- Thermal Sensor header
- Wi-Fi module with an antenna connector
- BIOS FlashBack button
- BIOS Switch button
- FlexKey button
- Clear CMOS button(s)
- Gniazdo zasilania
- ATX (24-pin) + 2x ATX12V (8-pin) + PCIe (8-pin)
- Wymiary [S x W] (mm)
- 305 X 277
- Wyposażenie dodatkowe
- 1x 1-to-3 ARGB splitter cable
- 1x 1-to-2 ARGB splitter cable
- 2x 1-to-4 fan splitter cable
- 2x ROG weave SATA 6G cable packages
- 1x 3-in-1 Thermistor cables pack
- 1x ROG DIMM.2 with heatsink
- 1x M.2 pad package for ROG Q-DIMM.2
- 2x Thermal pad for ROG Q-DIMM.2
- 1x ASUS WiFi Q-Antenna
- Zawiera baterię / akumulator
- Tak
- Informacje dodatkowe
- Operating System: Windows 11, Windows 10 64-bit
