- Waga
- 0.16 kg
- Typ urządzenia
- Przewodowe
- Obsługiwane protokoły / Zgodność z normami
- IEEE 802.3an 10GBase-T
- IEEE 802.3bz MGBASE-T (Multi Gigabit) 2.5 Gbit/s i 5 Gbit/s
- IEEE 802.3u 100 Base-T (RJ45)
- IEEE 802.1p Priorytetyzacja ruchu
- IEEE 802.3ab 1000 Base-T (RJ45)
- Typ złącza karty
- PCI Express x4 3.0
- Prędkość transmisji
- LAN: 10Gbps
- Wymiary [G x S x W] (mm)
- 122 x 100 x 18,5
- Waga (g)
- 82
- Informacje dodatkowe
- Performance: Quality of Service
- Jumbo frame support up to 16 KB
- Jumbo frame and VLAN tagging support
- Standard and low profile brackets included
- Compatible with Windows ® and Linux®
- Windows 7, 8.0, 8.1,10 (32/64-bit) or Server 2012
- Linux kernels 3.10, 3.12, 3.20, 4.2 or 4.4
- Interface:
- - PCI Express Gen-3(or2) x4 Host Bus Interface
- - 1 x 10Gbps RJ-45 Ethernet port
- - Pre-installed with full height bracket, also includes low profile bracket
- LED Indicator:
- - Speed: Green: 10G, Amber: 5G/2.5G/1G/100M
- - Activity: Green - Steady: No data transmission; Blink: Data transmission
- Operating Temperature: 0°C to 40°C
- Operating Humidity: 0% to 90% (Non-condensing)
- Certification: EMC: CE, FCC, EAC, BSMI, Class B
- Item dimensions (WxDxH)(mm/in):
- - 122 x 100 x 18.5/4.8 x 3.94 x 0.73
- - 82 x 68 x 18/3.22 x 2.67 x 0.7
- Item weight (g/lb.):
- - 82/0.18
- - 78/0.17
