- Waga
- 4.8 kg
- Architektura sieci LAN
- 10 Gigabit Ethernet
- Porty wej/wyj
- 1x 10M/100M/1G RJ-45 LAN
- 1x 10G SFP+ LAN
- 1x 10M/100M/1G RJ-45 WAN
- 1x 10G SFP+ WAN
- Ilość portów RJ-45 1GbE
- 2 szt.
- Ilość portów SFP+ 10GbE
- 2 szt.
- Port PoE
- Nie
- Tryb pracy
- Gateway / Brama dostępowa
- Typ obudowy
- Rack 1U
- Wymiary [G x S x W] (mm)
- 285,6 x 442,4 x 43,7
- Waga netto (kg)
- 3.420
- Informacje dodatkowe
- Enclosure materials - Front panel: aluminum CNC
- Enclosure materials - Top cover/base: SGCC steel
- Processor: Quad-core ARM® Cortex®-A57 at 1.7 GHz
- Memory information: 2 GB DDR4
- Management interface: Ethernet
- LCM display: 1.3" touchscreen
- Bootup animation: bootup in progress
- Firmware upgrade icon: firmware upgrading
- Button: Factory reset
- Power method: Universal AC input, 200-240VAC, 1.7A max., 50/60 Hz
- RPS DC input, 11.5VDC, 2.87A
- Power supply: AC/DC, internal, 50W
- Max. power consumption: 30W
- ESD/EMP protection: Air ± 15 kV, contact: ± 8 kV
- Operating temperature: -10 to 40° C (14 to 104° F)
- Operating humidity: 5 - 95% noncondensing
- Certifications: CE, FCC, IC
- LED - AC outlet/ RPS: Blue
- LED - Ethernet: Green/amber
- LED - SFP+: White/green
