- Typ obudowy
- Rack 2U
- System operacyjny
- Brak
- Model zainstalowanego procesora
- Intel® Xeon® Silver 4309Y Processor(12M Cache, 2.80 GHz)
- Ilość zainstalowanych procesorów
- 1 szt.
- Ilość rdzeni / wątków
- 8 / 16
- Pamięć zainstalowana (GB)
- 32
- Kontroler RAID
- RAID 930-8i
- Zamontowany dysk twardy
- 8x 2.5" SAS Open bay
- Złącza USB
- Przód: 1xUSB 3.0 1xUSB 2.0 ; Tył: 3xUSB 3.0 ; Wewnątrz: 1x USB 3.0
- Ilość zainstalowanych zasilaczy
- 1
- Moc zasilacza
- 1100 W
- Zawiera baterię / akumulator
- Tak
- Informacje dodatkowe
- Chipset: Intel C621A
- Memory:
- - 8 channels per CPU
- - 32x TruDDR4 (RDIMM/3DS) 3200 MHz DIMMs
- - Up to 1DPC & 2DPC @ 3200MHz
- - Max 8 TB with 32x 256 GB DIMMs
- - Intel Optane PMem 200 Series
- Disk:
- - Up to 40 total 2.5-inch drives bays
- - Up to 12x 3.5-inch or 24x 2.5-inch front bays
- - 4x 3.5-inch or 8x 2.5-inch mid drive bays
- - 2x 2.5-inch rear SAS/SATA/NVMe
- - Up to 32x 2.5-inch NVMe drives
- - 2x 7mm hot-swap rear SAS/SATA/NVMe for boot
- - 2x Internal M.2 with optional RAID 1
- RAID:
- - 12Gb SAS/SATA/RAID support
- - PCIe 3.0 and PCIe 4.0 adapters
- - Onboard SATA support with RAID
- - Onboard VROC NVMe support with RAID
- - Wider range of 8-, 16- and 32-port RAID adapters + SAS expander
- - 8- and 16-port HBAs
- - 12x Onboard NVMe ports
- - NVMe Retimer adapters for 16x NVMe
- Networking
- - Selectable OCP 3.0, 1GbE, 10GbE or 25GbE
- - Optional PCIe adapters
- - 1GbE dedicated management port
- Management and security:
- - XClarity Controller with upgrades
- - Full XClarity software suite including XClarity Administrator
- - Optional lockable front bezel
- - Optional intrusion switch
- - Support for External Diagnostics Handset
- - Platform Firmware Resiliency (PFR) hardware Root of Trust
