- Typ obudowy
- Rack 1U
- System operacyjny
- Brak
- Model zainstalowanego procesora
- Intel® Xeon® Silver 4314 Processor (24M Cache, 2.40 GHz)
- Ilość zainstalowanych procesorów
- 1 szt.
- Ilość rdzeni / wątków
- 16 / 32
- Pamięć zainstalowana (GB)
- 32
- Kontroler RAID
- RAID 930-8i
- Zamontowany dysk twardy
- 8x 2.5" SAS; Open bay
- Złącza USB
- Przód: 1xUSB 3.0 1xUSB 2.0 ; Tył: 3xUSB 3.0 ; Wewnątrz: 1x USB 3.0
- Ilość zainstalowanych zasilaczy
- 1
- Moc zasilacza
- 1100 W
- Zawiera baterię / akumulator
- Tak
- Informacje dodatkowe
- Chipset: Intel C621A
- Memory:
- - 8 channels per CPU
- - 32x TruDDR4 (RDIMM/3DS) 3200 MHz DIMMs
- - Up to 1DPC & 2DPC @ 3200MHz
- - Max 8 TB with 32x 256 GB DIMMs
- - Intel Optane PMem 200 Series
- Disk:
- - Up to 4x 3.5-inch or 10x 2.5-inch or 16x EDSFF front bays
- - 2x 2.5-inch rear SAS/SATA/NVMe
- - Up to 12x 2.5-inch NVMe
- - 2x 7mm hot-swap rear SAS/SATA/NVMe for boot
- - 2x Internal M.2 with optional RAID 1
- RAID:
- - 12Gb SAS/SATA/RAID support
- - PCIe 3.0 and PCIe 4.0 adapters
- - Onboard SATA support with RAID
- - Onboard VROC NVMe support with RAID
- - Wider range of 8- and 16-port RAID adapters
- - 8- and 16-port HBAs
- - 12x Onboard NVMe ports
- - NVMe Retimer adapters for 16x NVMe
- Networking:
- - Selectable OCP 3.0, 1GbE, 10GbE or 25GbE
- - Optional PCIe adapters
- - 1GbE dedicated management port
- Management and security:
- - XClarity Controller with upgrades
- - Full XClarity software suite including XClarity Administrator
- - Optional lockable front bezel
- - Optional intrusion switch
- - Support for External Diagnostics Handset
- - Platform Firmware Resiliency (PFR) hardware Root of Trust
