- Waga
- 1 kg
- Gniazdo procesora
- Socket 1700
- Obsługiwane typy procesorów
- Intel Core i3 12th Generation
- Intel Core i5 12th Generation
- Intel Core i7 12th Generation
- Intel Core i9 12th Generation
- Intel Core i3 13th Generation
- Intel Core i5 13th Generation
- Intel Core i7 13th Generation
- Intel Core i9 13th Generation
- Intel Core i3 14th Generation
- Intel Core i5 14th Generation
- Intel Core i7 14th Generation
- Intel Core i9 14th Generation
- Intel Celeron™ (Socket 1700)
- Intel Pentium™ (Socket 1700)
- Format płyty
- Micro-ATX
- BIOS
- 1 x 128 Mbit AMI UEFI BIOS PnP 1a, DMI 2.7, WfM 2, SM BIOS 2.7, ACPI 5
- Chipset płyty głównej
- Intel® B760
- Ilość złącz pamięci DDR5
- 4
- Maksymalna wielkość pamięci
- 256 GB
- Tryb pracy pamięci RAM
- Dual Channel
- Standard pamięci
- DDR5-4000
- DDR5-4800
- DDR5-5200
- DDR5-5600
- Uwagi do pamięci RAM
- 14th and 13th Generation Intel® Core™ i9/i7 Processors:
- - Support for DDR5 5600/5200/4800/4400 MT/s memory modules
- 13th Generation Intel Core i5/i3 and 12th Generation Intel Core,
- Pentium Gold and Celeron Processors:
- - Support for DDR5 4800/4400 MT/s memory modules
- Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
- (operate in non-ECC mode)
- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
- Zintegrowany kontroler SATA
- Chipset: 4x SATA III 6Gb/s - RAID 0,1,5,10 + 2x M.2
- Uwagi do kontrolera SATA
- CPU:
- - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support)
- (M2A_CPU)
- Chipset:
- - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support)
- (M2P_SB)
- - 4 x SATA 6Gb/s connectors
- RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
- Wbudowana karta graficzna
- Intel® HD Graphics
- Gniazda karty graficznej
- D-Sub
- HDMI
- DisplayPort
- Uwagi do karty graficznej
- - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
- Support for HDMI 2.1 version and HDCP 2.3.
- Support for native HDMI 2.1 TMDS compatible ports.
- - 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
- Support for DisplayPort 1.2 version and HDCP 2.3
- - 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
- Zintegrowana karta dźwiękowa
- Realtek ® 7.1 Surround Sound High Definition Audio CODEC
- Gniazda karty dźwiękowej
- Wewnętrzne gniazdo audio przedniego panelu
- 3x Audio Jack
- Wewnętrzne gniazdo S/PDIF Out
- Złącza PCI Express x16
- 1
- Złącza PCI Express x1
- 2
- Uwagi do złącz PCI
- CPU:
- - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
- The PCIEX16 slot can only support a graphics card or an NVMe SSD.
- Chipset:
- - 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1
- Port LAN
- 1x 1 Gigabit LAN Realtek®
- Maksymalna ilość portów USB 2.0
- 6
- Maksymalna ilość portów USB 3.x
- 6
- Porty USB na panelu tylnym
- 2x USB 2.0 + 3x USB 3.0
- Gniazda USB na płycie głównej
- 2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.0 Type-C (1 port)
- Port Wi-Fi
- Nie
- Port Bluetooth
- Nie
- Port PS/2
- Port combo klawiatury/myszy PS/2
- Port szeregowy (COM)
- 1x wewnętrzne gniazdo portu COM
- Port równoległy (LPT)
- 1x wewnętrzne gniazdo portu LPT
- Inne porty i gniazda
- CPU fan header
- 3x system fan headers
- Addressable LED strip headers
- RGB LED strip header
- Front panel header
- Front Panel Audio header (AAFP)
- Trusted Platform Module header
- Q-Flash Plus button
- Reset jumper
- Clear CMOS jumper
- Gniazdo zasilania
- ATX (24-pin) + ATX12V (8-pin)
- Wymiary [S x W] (mm)
- 244 x 174
- Opakowanie
- BOX
- Zawiera baterię / akumulator
- Tak
- Informacje dodatkowe
- Support for GIGABYTE Control Center (GCC)
- Support for Q-Flash
- Support for Q-Flash Plus
- Bundled Software:
- - Norton Internet Security (OEM version)
- - LAN bandwidth management software
- Support for Windows 10/11 64-bit
