- Waga
- 1.55 kg
- Gniazdo procesora
- Socket 1700
- Obsługiwane typy procesorów
- Intel Core i3 12th Generation
- Intel Core i5 12th Generation
- Intel Core i7 12th Generation
- Intel Core i9 12th Generation
- Intel Core i3 13th Generation
- Intel Core i5 13th Generation
- Intel Core i7 13th Generation
- Intel Core i9 13th Generation
- Intel Core i3 14th Generation
- Intel Core i5 14th Generation
- Intel Core i7 14th Generation
- Intel Core i9 14th Generation
- Intel Pentium™ (Socket 1700)
- Intel Celeron™ (Socket 1700)
- Uwagi do procesora
- Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max
- Technology 3.0
- Refer to www.asus.com for CPU support list
- Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types
- Format płyty
- Micro-ATX
- BIOS
- 128 Mb Flash ROM, UEFI AMI BIOS
- Chipset płyty głównej
- Intel® B760
- Ilość złącz pamięci DDR5
- 4
- Maksymalna wielkość pamięci
- 192 GB
- Tryb pracy pamięci RAM
- Dual Channel
- Standard pamięci
- DDR5-7800+ (OC)
- DDR5-7000 (OC)
- DDR5-6800 (OC)
- DDR5-6600 (OC)
- DDR5-6400 (OC)
- DDR5-6200 (OC)
- DDR5-6000 (OC)
- DDR5-5800 (OC)
- DDR5-5600
- DDR5-5400
- DDR5-5200
- DDR5-5000
- DDR5-4800
- Uwagi do pamięci RAM
- Supports Intel® Extreme Memory Profile (XMP)
- OptiMem
- Supported memory types, data rate (speed), and number of DRAM modules vary
- depending on the CPU and memory configuration, for more information please
- refer to CPU/Memory Support list under the Support tab of product
- information site or visit https://www.asus.com/support/
- Zintegrowany kontroler SATA
- Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10,5 + 3x M.2
- Uwagi do kontrolera SATA
- Intel® CoreTM Processors (14th & 13th & 12th Gen):
- - M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
- Intel® B760 Chipset:
- - M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
- - M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x2 mode)
- - 4 x SATA 6Gb/s ports
- Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10
- Wbudowana karta graficzna
- Brak lub Intel® UHD Graphics 730/750/770/Iris Xe (zależy od procesora)
- Gniazda karty graficznej
- HDMI
- DisplayPort
- Uwagi do karty graficznej
- Graphics specifications may vary between CPU types
- Please refer to www.intel.com for any updates
- Supports max. 4K@60Hz as specified in DisplayPort 1.4
- Supports 4K@60Hz as specified in HDMI 2.1
- Zintegrowana karta dźwiękowa
- Realtek ® 7.1 Surround Sound High Definition Audio CODEC
- Gniazda karty dźwiękowej
- 5x Audio Jack
- Wewnętrzne gniazdo audio przedniego panelu
- Wyjście optyczne S/PDIF
- Uwagi do karty dźwiękowej
- Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
- - Audio Shielding
- - Premium audio capacitors
- - Dedicated audio PCB layers
- Złącza PCI Express x16
- 1
- Złącza PCI Express x4
- 1
- Złącza PCI Express x1
- 1
- Uwagi do złącz PCI
- Intel® CoreTM Processors (14th & 13th & 12th Gen):
- - 1 x PCIe 5.0 x16 slot
- Intel® B760 Chipset:
- - 1 x PCIe 4.0 x4 slot
- - 1 x PCIe 3.0 x1 slot
- To ensure compatibility of the device installed, please refer to
- https://www.asus.com/support/ for the list of supported peripherals
- Port LAN
- 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®)
- Uwagi do karty sieciowej
- TUF LANGuard
- Maksymalna ilość portów USB 2.0
- 9
- Maksymalna ilość portów USB 3.x
- 7
- Porty USB na panelu tylnym
- 4x USB 2.0 + 2x USB 3.0 + 1x USB 3.1 + 1x USB 3.2 Type-C
- Gniazda USB na płycie głównej
- 3x USB 2.0 (5 portów) + 1x USB 3.0 (2 porty) + 1x USB 3.1 Type-C (1 port)
- Port Wi-Fi
- IEEE 802.11a/b/g/n/ac/ax
- Port Bluetooth
- Bluetooth V5.3
- Uwagi do WiFi / BT
- Supports 2.4/5/6GHz frequency band
- Wi-Fi 6GHz frequency band regulatory may vary between countries
- The Bluetooth version may vary, please refer to the Wi-Fi module
- manufacturer's website for the latest specifications
- Inne porty i gniazda
- 4-pin CPU Fan header
- 4-pin CPU OPT Fan header
- 4-pin AIO Pump header
- 3x 4-pin Chassis Fan headers
- 3x Addressable Gen 2 header
- Clear CMOS header
- Thunderbolt header
- Gniazdo zasilania
- ATX (24-pin) + 2x ATX12V (8-pin)
- Wymiary [S x W] (mm)
- 244 x 244
- Opakowanie
- BOX
- Wyposażenie dodatkowe
- 2 x SATA 6Gb/s cables
- 1 x ASUS Q-Antenna
- 1 x M.2 Rubber Package
- 1 x TUF Gaming sticker
- 2 x Screw packages for M.2 SSD
- 1 x TUF Certification card
- 1 x User guide
- Zawiera baterię / akumulator
- Tak
- Informacje dodatkowe
- Manageability: WOL by PME, PXE
- Operating System: Windows® 11, Windows® 10 64-bit
