- Waga
- 1.2 kg
- Gniazdo procesora
- Socket 1700
- Obsługiwane typy procesorów
- Intel Core i3 12th Generation
- Intel Core i5 12th Generation
- Intel Core i7 12th Generation
- Intel Core i9 12th Generation
- Intel Core i3 13th Generation
- Intel Core i5 13th Generation
- Intel Core i7 13th Generation
- Intel Core i9 13th Generation
- Intel Pentium™ (Socket 1700)
- Intel Celeron™ (Socket 1700)
- Uwagi do procesora
- Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max
- Technology 3.0
- Refer to www.asus.com for CPU support list
- Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types
- Format płyty
- Mini-ITX
- BIOS
- 128 Mb Flash ROM, UEFI AMI BIOS
- Chipset płyty głównej
- Intel® B760
- Ilość złącz pamięci DDR5
- 2
- Maksymalna wielkość pamięci
- 64 GB
- Tryb pracy pamięci RAM
- Dual Channel
- Standard pamięci
- DDR5-4800
- DDR5-5000
- DDR5-5200
- DDR5-5400
- DDR5-5600
- DDR5-5800 (OC)
- DDR5-6000 (OC)
- DDR5-6200 (OC)
- DDR5-6400 (OC)
- DDR5-6600 (OC)
- DDR5-6800 (OC)
- DDR5-7000 (OC)
- DDR5-7200 (OC)
- DDR5-7466 (OC)
- DDR5-7600 (OC)
- Uwagi do pamięci RAM
- Supports Intel® Extreme Memory Profile (XMP)
- OptiMem II
- Supported memory types, data rate(Speed), and number of DRAM modules vary
- depending on the CPU and memory configuration, for more information refer
- to www.asus.com for memory support list
- Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists)
- Zintegrowany kontroler SATA
- Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10,5 + 2x M.2
- Uwagi do kontrolera SATA
- Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
- Intel® 13th & 12th Gen Processors:
- - M.2_1 slot (Key M), type 2260/2280 (supports PCIe 4.0 x4 mode)
- Intel® B760 Chipset:
- - M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
- - 4 x SATA 6Gb/s ports
- Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10
- Wbudowana karta graficzna
- Brak lub Intel® UHD Graphics 730/750/770/Iris Xe (zależy od procesora)
- Gniazda karty graficznej
- HDMI
- DisplayPort
- Uwagi do karty graficznej
- Graphics specifications may vary between CPU types
- Please refer to www.intel.com for any updates
- Supports 4K@60Hz as specified in HDMI 2.1
- Supports max. 8K@60Hz as specified in DisplayPort 1.4
- Zintegrowana karta dźwiękowa
- ROG SupremeFX S1220 8-Channel High Definition Audio CODEC
- Gniazda karty dźwiękowej
- 5x Audio Jack
- Wewnętrzne gniazdo S/PDIF Out
- Uwagi do karty dźwiękowej
- - Impedance sense for front and rear headphone outputs
- - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- - High quality 120 dB SNR stereo playback output and 113 dB SNR recording
- input (Line-in)
- - Supports up to 32-Bit/192 kHz playback
- Audio Features
- - SupremeFX Shielding Technology
- - Savitech SV3H712 AMP
- - Premium audio capacitors
- Due to limitations in HAD bandwidth, 32-Bit/192 kHz is not supported for
- 7.1 Surround Sound audio
- Złącza PCI Express x16
- 1
- Złącza PCI Express x1
- 0
- Uwagi do złącz PCI
- Intel® 13th & 12th Gen Processors:
- - 1 x PCIe 5.0 x16 slot
- To ensure compatibility of the device installed, please refer to
- https://www.asus.com/support/ for the list of supported peripherals
- Port LAN
- 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Intel®)
- Uwagi do karty sieciowej
- ASUS LANGuard
- Maksymalna ilość portów USB 2.0
- 5
- Maksymalna ilość portów USB 3.x
- 8
- Porty USB na panelu tylnym
- 3x USB 2.0 + 3x USB 3.0 + 1x USB 3.0 Type-C + 1x USB 3.2 Type-C
- Gniazda USB na płycie głównej
- 1x USB 2.0 (2 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.1 Type-C (1 port)
- Port Wi-Fi
- IEEE 802.11a/b/g/n/ac/ax
- Port Bluetooth
- Bluetooth V5.3
- Port PS/2
- Brak
- Port szeregowy (COM)
- Brak
- Port równoległy (LPT)
- Brak
- Inne porty i gniazda
- 4-pin AIO Pump header
- Addressable Gen 2 header
- AURA RGB header
- Thermal Sensor header
- Gniazdo anteny WiFi
- Gniazdo zasilania
- ATX (24-pin) + ATX12V (8-pin)
- Wymiary [S x W] (mm)
- 170 x 170
- Opakowanie
- BOX
- Wyposażenie dodatkowe
- 2x SATA 6Gb/s cables; ROG USB2.0 splitter cable; Panel cable; Additional
- Cooling Kit, Thermal pad for M.2, ASUS Wi-Fi moving antennas, Cable ties
- package, M.2 Rubber Package, 2x Screw packages for M.2 SSD, M.2 bracket
- ROG key chain, ROG STRIX stickers, ROG STRIX thank you card, User manual
- Zawiera baterię / akumulator
- Tak
- Informacje dodatkowe
- Windows® 11 64-bit, Windows® 10 64-bit
- 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
- Supports 2.4/5/6GHz frequency band
- WiFi 6E 6GHz regulatory may vary between countries
