- Waga
- 1.93 kg
- Gniazdo procesora
- Socket 1700
- Obsługiwane typy procesorów
- Intel Core i3 12th Generation
- Intel Core i5 12th Generation
- Intel Core i7 12th Generation
- Intel Core i9 12th Generation
- Intel Core i3 13th Generation
- Intel Core i5 13th Generation
- Intel Core i7 13th Generation
- Intel Core i9 13th Generation
- Intel Celeron™ (Socket 1700)
- Intel Pentium™ (Socket 1700)
- Uwagi do procesora
- Supports Intel® 10 nm CPU
- Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost
- Max Technology 3.0**
- Refer to www.asus.com for CPU support list
- Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types
- Format płyty
- ATX
- BIOS
- 128 Mb WOL by PME, PXE
- Chipset płyty głównej
- Intel® B760
- Ilość złącz pamięci DDR5
- 4
- Maksymalna wielkość pamięci
- 192 GB
- Tryb pracy pamięci RAM
- Dual Channel
- Uwagi do pamięci RAM
- Non-ECC, Un-buffered Memory
- Supports Intel® Extreme Memory Profile (XMP)
- OptiMem II
- Supported memory types, data rate (speed), and number of DRAM modules
- vary depending on the CPU and memory configuration, for more information
- please refer to CPU/Memory Support list under the Support tab of product
- information site or visit https://www.asus.com/support/
- Zintegrowany kontroler SATA
- Chipset+CPU: 4x SATA III 6Gb/s + 3x M.2
- Uwagi do kontrolera SATA
- Intel® 13th & 12th Gen Processors:
- - M.2_1 slot (Key M), type 2242/2260/2280/22110
- Intel® B760 Chipset:
- - M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 mode)
- - M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
- - 4 x SATA 6Gb/s ports
- Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10
- M.2_2 slot shares bandwidth with PCIe X1 and WiFi module and will run
- PCIe 3.0 x2 by default. You need to set M.2_2 running at PCIe 3.0 x4 by
- by manually enabled in BIOS
- Wbudowana karta graficzna
- Brak lub Intel® UHD Graphics 730/750/770/Iris Xe (zależy od procesora)
- Gniazda karty graficznej
- HDMI
- DisplayPort
- Uwagi do karty graficznej
- Graphics specifications may vary between CPU types
- Please refer to www.intel.com for any updates
- Supports 4K@60Hz as specified in HDMI 2.1
- Support max. 8K@60Hz as specified in DisplayPort 1.4
- Zintegrowana karta dźwiękowa
- Realtek ® 7.1 Surround Sound High Definition Audio CODEC
- Gniazda karty dźwiękowej
- 5x Audio Jack
- Wewnętrzne gniazdo audio przedniego panelu
- Uwagi do karty dźwiękowej
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
- Premium audio capacitors
- Dedicated audio PCB layers
- Audio cover
- Unique de-pop circuit
- Złącza PCI Express x16
- 2
- Złącza PCI Express x1
- 1
- Uwagi do złącz PCI
- Intel® 13th & 12th Gen Processors:
- - 1 x PCIe 5.0/4.0/3.0 x16 slot
- Intel® B760 Chipset:
- - 1 x PCIe 4.0 x16 slot (supports x4 mode)
- - 1 x PCIe 3.0 x1 slot
- PCIe X1 shares bandwidth with M.2_2. PCIe X1 will be disable when M.2_2
- runs at PCIe x4 mode by manually enabled
- Port LAN
- 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®)
- 1x 1 Gigabit LAN Intel®
- Maksymalna ilość portów USB 2.0
- 8
- Maksymalna ilość portów USB 3.x
- 9
- Porty USB na panelu tylnym
- 4x USB 2.0 + 4x USB 3.0 + 1x USB 3.1 + 1x USB 3.1 Type-C
- Gniazda USB na płycie głównej
- 2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.2 Type-C (1 port)
- Port Wi-Fi
- IEEE 802.11a/b/g/n/ac/ax
- Port Bluetooth
- Bluetooth V5.2
- Port szeregowy (COM)
- 1x wewnętrzne gniazdo portu COM
- Port równoległy (LPT)
- Brak
- Inne porty i gniazda
- 4-pin CPU Fan header
- 4-pin CPU OPT Fan header
- 4-pin AIO Pump header
- 4x 4-pin Chassis Fan headers
- 3x Addressable Gen 2 header
- AURA RGB header
- Clear CMOS header
- SPI TPM header (14-1pin)
- Thermal Sensor header
- Thunderbolt header
- Gniazdo zasilania
- ATX (24-pin) + ATX12V (8-pin) + ATX12V (4-pin) + PCIe (6-pin)
- Wymiary [S x W] (mm)
- 305 x 244
- Opakowanie
- BOX
- Wyposażenie dodatkowe
- 2 x SATA 6Gb/s cables
- 1 x ASUS Wi-Fi moving antennas
- 2 x M.2 Rubber packages
- 1 x ProArt ruler
- 1 x Q-connector
- 1 x ACC Express Activation Key Card
- 1 x User guide
- Zawiera baterię / akumulator
- Tak
- Informacje dodatkowe
- Operating System: Windows® 11, Windows® 10 64-bit
