- Waga
- 1.41 kg
- Gniazdo procesora
- Socket AM5
- Obsługiwane typy procesorów
- AMD Ryzen™ (AM5)
- Uwagi do procesora
- Refer to www.asus.com for CPU support list
- Format płyty
- Micro-ATX
- BIOS
- 256 Mb Flash ROM, UEFI AMI BIOS
- Chipset płyty głównej
- AMD B650
- Ilość złącz pamięci DDR5
- 4
- Maksymalna wielkość pamięci
- 192 GB
- Tryb pracy pamięci RAM
- Dual Channel
- Standard pamięci
- DDR5-4800
- DDR5-5000
- DDR5-5200
- DDR5-5400 (OC)
- DDR5-5600 (OC)
- DDR5-5800 (OC)
- DDR5-6000 (OC)
- DDR5-6200 (OC)
- DDR5-6400 + (OC)
- Uwagi do pamięci RAM
- ECC and Non-ECC, Un-buffered Memory
- Supports AMD Extended Profiles for Overclocking (EXPO™)
- OptiMem II
- Supported memory types, data rate (speed), and number of DRAM modules vary
- depending on the CPU and memory configuration, for more information please
- refer to CPU/Memory Support list under the Support tab of product
- information site or visit https://www.asus.com/support/
- Non-ECC, un-buffered DDR5 memory supports On-Die ECC function
- Zintegrowany kontroler SATA
- Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 2x M.2 - RAID 0, 1, 10
- Uwagi do kontrolera SATA
- Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
- AMD Ryzen™ 7000 Series Desktop Processors
- - M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
- AMD B650 Chipset
- - M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
- - 4 x SATA 6Gb/s ports
- AMD RAIDXpert2 Technology supports both PCIe and SATA 0/1/10 RAID
- Wbudowana karta graficzna
- Brak lub AMD Radeon™ Graphics (zależy od procesora)
- Gniazda karty graficznej
- HDMI
- VGA
- DisplayPort
- Uwagi do karty graficznej
- Graphics specifications may vary between CPU types. Please refer to AMD C
- Supports max. 8K@60Hz as specified in DisplayPort 1.4
- Supports 4K@60Hz as specified in HDMI 2.1
- Zintegrowana karta dźwiękowa
- Realtek ® 7.1 Surround Sound High Definition Audio CODEC
- Gniazda karty dźwiękowej
- 3x Audio Jack
- Wewnętrzne gniazdo audio przedniego panelu
- Wewnętrzne gniazdo S/PDIF Out
- Uwagi do karty dźwiękowej
- Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback"
- - Audio Shielding
- - Premium audio capacitors
- - Dedicated audio PCB layers
- A chassis with an HD audio module in the front panel is required to
- support 7.1 Surround Sound audio output
- Złącza PCI Express x16
- 3
- Uwagi do złącz PCI
- AMD Ryzen™ 7000 Series Desktop Processors:
- - 1 x PCIe 4.0 x16 slot (supports x16 mode)
- AMD B650 Chipset:
- - 2 x PCIe 4.0 x16 slots (support x1 mode)
- To ensure compatibility of the device installed, please refer to
- https://www.asus.com/support/ for the list of supported peripherals.
- Port LAN
- 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Intel®)
- Maksymalna ilość portów USB 2.0
- 8
- Maksymalna ilość portów USB 3.x
- 7
- Porty USB na panelu tylnym
- 4x USB 2.0 + 2x USB 3.0 + 2x USB 3.1
- Gniazda USB na płycie głównej
- 2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.0 Type-C (1 port)
- Port Wi-Fi
- IEEE 802.11a/b/g/n/ac/ax
- Port Bluetooth
- Bluetooth V5.2
- Uwagi do WiFi / BT
- 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
- Supports 2.4/5GHz frequency band
- The Bluetooth version may vary, please refer to the Wi-Fi module
- manufacturer's website for the latest specifications
- Port PS/2
- Port combo klawiatury/myszy PS/2
- Port szeregowy (COM)
- 1x wewnętrzne gniazdo portu COM
- Inne porty i gniazda
- 3x Addressable Gen 2 header
- Clear CMOS header
- 4-pin CPU Fan header
- 4-pin CPU OPT Fan header
- 3x 4-pin Chassis Fan headers
- SPI TPM header (14-1pin)
- AURA RGB header
- Gniazdo zasilania
- ATX (24-pin) + ATX12V (8-pin) + ATX12V (4-pin)
- Wymiary [S x W] (mm)
- 244 x 244
- Opakowanie
- BOX
- Wyposażenie dodatkowe
- - 2 x SATA 6Gb/s cables
- - 1 x ASUS Wi-Fi moving antennas
- - 1 x I/O Shield
- - 1 x Screw package for M.2 SSD
- - 1 x User guide
- Zawiera baterię / akumulator
- Tak
- Informacje dodatkowe
- Manageability: WOL by PME, PXE
- Operating System: Windows® 11, Windows® 10 64-bit
